OVERVIEW The GE 9HA is a heavy-duty H-class gas turbine built for 50 Hz power generation. It is air-cooled, which distinguishes it from earlier steam-cooled H-class designs. GE Vernova markets it as one of the most efficient heavy-duty gas turbines in the 50 Hz market. It entered commercial service with the 9HA.01 at EDF's Bouchain plant in France in 2016. The manufacturer is now GE Vernova (formerly GE Power). Model: GE 9HA.01 Manufacturer: General Electric Year of Manufacture: 2015 Condition: Rebuild Needed Frequency: 50 Hz Configuration: Simple cycle gas turbine and generator package Quantity available: 1 GUARANTEED PERFORMANCE FROM SELLER DOCUMENT (SITE-RATED, NOT ISO) Gross power output on natural gas: 372.646 MW Gross power output on diesel oil: 368.783 MW Gross heat rate on natural gas: 8,825 kJ/kWh Gross heat rate on diesel oil: 9,411 kJ/kWh Fuel capability: Dual fuel, natural gas primary, diesel oil backup ISO BASELINE PERFORMANCE FROM GE PUBLISHED DATASHEETS These figures represent GE's published ISO-condition ratings for the 9HA.01 model class and provide the reference point against which the site-rated figures above should be understood. ISO conditions are 59 degrees Fahrenheit, sea level, and 60 percent relative humidity. Simple cycle net output at ISO: 397 MW (original 2014 rating); 448 MW (current GE Vernova uprated rating) Simple cycle net heat rate at ISO: 8,220 Btu/kWh or 8,673 kJ/kWh Simple cycle net efficiency at ISO: greater than 41 percent Pressure ratio: 21.8 Turbine speed: 3,000 rpm Exhaust temperature: 1,146 degrees Fahrenheit or 619 degrees Celsius Exhaust flow: 1,822 lbs/sec Combined cycle plant output in 1x1 configuration at ISO: 592 MW Combined cycle plant efficiency at ISO: greater than 61 percent MECHANICAL ARCHITECTURE 14-stage axial flow compressor with variable inlet guide vanes and three sets of variable stator vanes. Titanium first-stage rotating blade row. All compressor blades are super-finished and field replaceable. Combustion system is DLN 2.6 plus with 16 combustion chambers. Single-crystal alloy turbine blades with thermal barrier coatings. Air-cooled hot gas path, no steam cooling required. Control system is GE Mark VIe. OPERATIONAL CHARACTERISTICS Ramp rate: up to 60 MW per minute Hot start combined cycle load: under 30 minutes Gas turbine turndown: to approximately 40 percent load while maintaining emissions compliance NOx emissions: below 25 ppm on natural gas at baseload Hydrogen capability: 50 percent by volume blended with natural gas, with technology pathway to 100 percent Build notes: Requires Upgrades with GE costing an additional $47-$53 Million - All Materials in Boxes. Pricing notes: LOT PRICE
